F2.4 1/2.3″ 1.7mm 16mp m12 s mount fisheye sports camera board lens – ACHIR01724DV
SPECIFICATION
| Focal Length | 1.7mm |
| Resolution | 16MP |
| Format | 1/2.3″ |
| Mount | M12x0.5 |
| F/NO | F2.4 |
| Back Focus | 2.6mm |
| Max Image Circle | Φ4.64 |
| Angle of View (V )(H/V/D) | 185° |
| WD(m) | 0.4m~∞ |
| Design Wavelength | 420~680nm |
| RI | 78% |
| Distortion | <-20.4% |
| Front Diameter | Φ16.5 |
| Construction | 7G+IR |
| TTL | 20mm |
| Model | ACHIR01724DV |
PS: F2.4 1/2.3″ 1.7mm 16mp m12 s mount fisheye sports camera board lens, 16mp m12 fisheye lens
