12-40mm F2.1 4mp or 4K P-iris CS / D19 mount motorized focus zoom cctv varifocal lens for 1/1.8″ format – ACMZ118BP1240ICRCSR1
SPECIFICATION
| Focal Length: | 12-40mm | ||
| Sensor: | 1/1.8” CCD/CMOS | ||
| Image Format(HxV,D): | 7.15×5.36, 8.93 | ||
| FNo.: | F2.1 | ||
| TV Distortion: | -5.9%W~-0.2%T | ||
| Resolution: | 4MP or 4K | ||
| Relative illumination: | >45% | ||
| Iris: | P-Iris with ICR | ||
| Zoom: | Motorized | ||
| Focus: | Motorized | ||
| Back Focal Length: | 7.29mm~9.08mm（in air） | ||
| F.O.V.: | 1/1.8” | 1/2” | |
| D | 43.3°~14.3° | 38.3°~12.8° | |
| H | 33.9°~11.5° | 30.1°~10.3° | |
| V | 25°~8.6° | 22.3°~7.7° | |
| Lens Effective Diameter: | Front Φ23mm | ||
| Back Φ9.6mm | |||
| Lens construction: | 12-10 | ||
| Max Chief Ray Angle | 7.6° | ||
| M.O.D.: | 0.6m | ||
| Mount: | CS mount / Φ19 mount | ||
| TTL: | 63.32mm | ||
| Dimension: | Φ33×52.99xΦ51mm | ||
| Model: | ACMZ118BP1240ICRCSR1 | ||
PS: 12-40mm 4mp P-iris CS mount motorized focus zoom cctv varifocal lens for 1/1.8″ format, M12 Motorized Varifocal zoom Lens 3.7-14.8mm
