Global shutter Sony IMX264 CMOS GigE vision V2.0 5mp C mount machine industrial camera with 2/3″ sensor – ACMVCA05010GM/GC
Key Features :
- Adopts GigE interface and max. Transmission distance of 100 meters without relay.
- Supports auto and manual adjustment for exposure control, LUT, Gamma correction, etc.
- Up to 128 MB local memory for burst transmission and retransmission.
- Supports hardware trigger, software trigger, etc.
- Compatible with GigE Vision Protocol V2.0, GenICam Standard, and third-party software based on these protocol and standard.
High End Choice For :
- ACMVCA05010GM/GC camera adopts Sony IMX264 sensor to provide high-quality image. It uses GigE interface to transmit non-compressed images in real time with max. frame rate reaching 23.5 fps.
SPECIFICATION
Model: | ACMVCA05010GM | ACMVCA05010GC | ||
Camera | ||||
Sensor type: | CMOS, global shutter | |||
Sensor model: | Sony IMX264 | |||
Pixel size : | 3.45μm x 3.45 μm | |||
Sensor size: | 2/3” | |||
Resolution: | 2448 x 2048 | |||
Max. frame rate: | 23.5 fps @2448 x 2048 | |||
Dynamic range: | 72 dB | |||
SNR: | 40.2 dB | |||
Gain: | 0 dB to 20 dB | 0 dB to 17 dB | ||
Exposure time : | UltraShort exposure mode: 1 μs to 14 μs | |||
Normal exposure mode: 15 μs to 10 s | ||||
Shutter mode : | Off/Once/Continuous exposure mode | |||
Mono/color : | Mono | Color | ||
Pixel format: | Mono 8/10/10p/12/12p | Mono 8/10/12, Bayer RG 8/10/10p/12/12p, YUV422Packed, YUV422_YUYV_Packed, RGB 8, BGR 8 | ||
Binning: | Supports 1×2, 1×4, 2×1, 2×2, 2×4, 4×1, 4×2, 4×4 | |||
Decimation: | Supports 2 x 2 | |||
Reverse image : | Supports horizontal and vertical reverse image output | |||
Image buffer: | 128 MB | |||
Electrical features | ||||
Data interface: | Gigabit Ethernet | |||
Digital I/O : | 6-pin Hirose connector provides power and I/O, including opto-isolated input x 1 (Line0), opto-isolated output x 1(Line1), and bi-directional non-isolated I/O x 1 (Line2) | |||
Power supply : | 5 VDC to 15 VDC, supports PoE power supply | |||
Power consumption: | Approx. 3.2 W@12 VDC | Approx. 3.1 W@12 VDC | ||
Structure | ||||
Lens mount : | C-Mount | |||
Dimension : | 29 mm × 29 mm × 42 mm (1.1″ × 1.1″ × 1.7″) | |||
Weight: | Approx. 68 g (0.15 lb.) | |||
Ingress protection: | IP30 (under proper lens installation and wiring) | |||
Temperature : | Working temperature: 0°C to 50°C (32 to 122°F) Storage temperature: -30°C to 70°C (-22 to 158°F) | |||
Humidity: | 20% to 80% RH, without condensation | |||
General | ||||
Client software: | MVS or third-party software meeting with GigE Vision Protocol | |||
Operation system: | 32/64-bit Windows XP/7/10, 32/64-bit Linux and 64-bit MacOS | |||
Compatibility : | GigE Vision V2.0, GenICam | |||
Certifications : | CE, FCC, RoHS, KC |
PS: Sony IMX264 CMOS GigE vision V2.0 5mp C mount machine industrial camera with 2/3″ sensor, 5mp 25mm c mount industrial lens for 2/3 sensor
